Intel SSD DC S3610 Series 1.6TB SATA Enterprise SSD
Intel SSD DC S3610 Series 1.6TB SATA Enterprise SSD
Price on Request
PN:SSDSC2BX016T4
Quick Specifications
Memory1.6TB / 1600GB
PCIeSATA 6Gb/s (SATA III)
Form Factor2.5-inch 7mm
Product CollectionIntel SSD DC S3610 Series
Product TypeHigh-Endurance Enterprise SATA SSD
NAND FlashIntel 20nm High Endurance Technology (HET) MLC NAND
Sequential ReadUp to 550 MB/s
Sequential WriteUp to 500 MB/s
1
Order on WhatsApp
Share to:

Technical Specifications

Hardware Features

Brand
Intel
Model
Intel SSD DC S3610 Series 1.6TB
Model Number
SSDSC2BX016T4
Capacity
1.6TB / 1600GB
Form Factor
2.5-inch 7mm
Interface
SATA 6Gb/s (SATA III)
Interface Transfer Rate
600 MB/s (6.0 Gbps)

Network Performance

Sequential Read Speed
Up to 550 MB/s
Sequential Write Speed
Up to 500 MB/s
Read Latency (Typical)
55 µs
Write Latency (Typical)
66 µs

System and Support

Power Loss Protection
Enhanced Power Loss Protection (Full Capacitor Array)
MTBF
2,000,000 Hours
Operating Temperature
0–70°C
Service and Support
INOVEXA TECHNOLOGIES Bangladesh
Mean Time Between Failures (MTBF)
2,000,000 Hours
Power Loss Protection (PLP)
Enhanced Power Loss Protection (Full Capacitor Array)
Active Power Consumption
6.4W Read / 6.8W Write
Idle Power Consumption
0.7W
Non-Operating Temperature
-55°C to 95°C
Service & Support
INOVEXA TECHNOLOGIES Bangladesh

General Specifications

Product Collection
Intel SSD DC S3610 Series
Product Type
High-Endurance Enterprise SATA SSD
NAND Flash
Intel 20nm High Endurance Technology (HET) MLC NAND
Sequential Read
Up to 550 MB/s
Sequential Write
Up to 500 MB/s
Random Read (100% Span)
Up to 84,000 IOPS (4KB)
Random Write (100% Span)
Up to 27,000 IOPS (4KB)
Endurance (PBW / DWPD)
10.7 PBW (10,700 TBW) / 3.0 DWPD for 5 Years
Hardware Encryption
AES 256-bit Encryption
UBER
1 Sector per 10¹⁷ Bits Read
Active Power
6.4W Active Read / 6.8W Active Write
Idle Power
0.7W
NAND Flash Type
Intel 20nm High Endurance Technology (HET) MLC NAND
Random Read (4KB, 100% Span)
Up to 84,000 IOPS (4KB)
Random Write (4KB, 100% Span)
Up to 27,000 IOPS (4KB)
Endurance Rating (TBW / DWPD)
10.7 PBW (10,700 TBW) / 3.0 DWPD
Uncorrectable Bit Error Rate (UBER)
1 sector per 10¹⁷ bits read
End-to-End Data Protection
Yes, comprehensive internal path CRC
Enterprise Duty Cycle
24×7 Continuous Operation
Vibration Operating
2.17 GRMS (5-700 Hz)
Shock Operating
1,000 G (0.5 ms)
Technical Guidance
Server backplane and carrier compatibility verification available

Product Description

Intel SSD DC S3610 Series 1.6TB SATA Enterprise SSD

Need extreme write endurance and rock-solid reliability for demanding server databases or caching tiers? The Intel SSD DC S3610 Series 1.6TB SATA Enterprise SSD is a high-endurance, mixed-use enterprise SATA solid-state drive built with genuine Intel 20nm High Endurance Technology (HET) MLC NAND. Engineered for write-heavy database transaction logging, hypervisor swap partitions, dynamic caching layers, and high-frequency OLTP workloads, it delivers sequential reads up to 550 MB/s, sequential writes up to 500 mb/s, and Up to 84,000 IOPS (4KB) random-read IOPS. With an extraordinary endurance profile of 10.7 PBW (10,700 TBW) / 3.0 DWPD over 5 years, full capacitor-backed Power Loss Protection, and AES 256-bit encryption, the DC S3610 ensures sustained multi-year endurance and data protection for mission-critical enterprise server environments in Bangladesh.

Enterprise Performance and Architectural Overview

Unlike standard read-centric TLC SSDs, the Intel SSD DC S3610 Series utilizes premium High Endurance Technology (HET) Multi-Level Cell (MLC) flash silicon. This specialized memory architecture allows the drive to handle 3 full drive writes per day (3.0 DWPD) continuously for 5 years without performance degradation. With dedicated hardware power-loss protection capacitors, end-to-end data integrity protection, and 2.0 million hours MTBF, the DC S3610 is ideal for database write logs (WAL), hyper-converged storage nodes, caching tiers, and enterprise server boot drives across Bangladesh.

Advanced Technical Standards and Multi-Gigabit Support

  • Intel 20nm HET MLC NAND: Industrial-grade High Endurance Technology MLC flash delivers exceptional write endurance (3.0 DWPD) and long-term data retention.
  • Massive Write Endurance (10.7 PBW (10,700 TBW) / 3.0 DWPD): Designed for write-intensive enterprise workloads, providing 10.7 PBW (10,700 TBW) / 3.0 DWPD over 5 years of continuous non-stop writing.
  • Enhanced Power Loss Protection (PLP): Full discrete tantalum capacitor array guarantees that all in-flight cache writes are flushed safely to flash if server power fails.
  • Predictable Consistent I/O Performance: Delivers up to 550 MB/s sequential read, Up to 500 MB/s write, and stable low-latency IOPS under full queue depths.
  • End-to-End Data Path Protection: Internal controller circuitry performs multi-stage parity and CRC checks to prevent any silent data corruption.
  • Hardware AES 256-bit Encryption: Provides real-time hardware-level data encryption to protect enterprise database records and confidential assets.

Reliability and Long-Term Performance in Bangladesh

Electronic components and network equipment in our region need to be durable to handle varying environmental conditions. Every enterprise unit supplied by INOVEXA Technologies is tested under intensive operational benchmarks to guarantee 24/7 continuous operation, optimized thermal airflow, and long lifespan.

Secure Your High-Performance Hardware at INOVEXA

Do not let hardware bottlenecks hold back your business network or workstation. We maintain ready stock of genuine enterprise hardware backed by fast nationwide delivery across Bangladesh, replacement warranty, and dedicated engineering support.

Benefits & Enterprise Applications

Enterprise Applications & Deployments

Database Write-Ahead Logging (WAL / Redo Logs)

Handles high-frequency write commits in Oracle, PostgreSQL, MySQL, and MS SQL databases without wearout.

Hypervisor Swap & Dynamic Caching Layers

Acts as a high-speed L2 caching layer in ZFS (L2ARC/SLOG), Ceph, and VMware vSAN pools.

High-Density Virtualization Clusters

Provides resilient shared storage for mixed-workload virtual machines with heavy write cycles.

Enterprise OS Boot & Log Partitions

Ensures zero downtime and data protection for mission-critical Linux/Windows server operating systems.

Financial & Transaction Processing Nodes

Maintains sub-millisecond commit latency and hardware encryption for transactional systems.

Operational & ROI Benefits

Extreme 3.0 DWPD Endurance

Outlasts standard TLC SSDs by 3x to 5x in heavy write-intensive enterprise applications.

Genuine Intel HET MLC NAND

Utilizes high-endurance 2-bit-per-cell MLC flash for greater stability under continuous write stress.

Full Hardware Power-Loss Protection

Prevents in-flight data corruption and file system inconsistencies during power outages.

Universal SATA Compatibility

Drop-in replacement for any 2.5-inch SATA drive tray in Dell, HPE, Supermicro, or Cisco servers.

System & Hardware Compatibility

Certified Operating Systems & Hypervisors

  • VMware ESXi 6.7/7.0/8.0
  • Proxmox VE 7/8
  • Windows Server 2016/2019/2022
  • RHEL 7/8/9
  • Ubuntu Server 20.04/22.04/24.04
  • Debian
  • FreeBSD / TrueNAS

Hardware Chassis & Interconnect Platform

  • Dell PowerEdge (13G/14G/15G)
  • HPE ProLiant (Gen9/Gen10/Gen11)
  • Supermicro X10/X11/X12
  • Cisco UCS
  • Lenovo ThinkSystem
  • Standard SATA Server Motherboards

Supported Network & Storage Protocols

SATA 6Gb/s (Revision 3.2)AHCINCQS.M.A.R.T.AES 256-bit Hardware EncryptionEnhanced Power Loss Protection (PLP)

Deployment & Buying Guide

Recommended Deployment Pairing

Designed for any enterprise server or workstation with 2.5-inch SATA drive bays and SATA 6Gb/s backplanes.

Ideal Infrastructure Use Cases (Best For)

High Write-Cycle Database Servers (OLTP, SQL, NoSQL)
ZFS SLOG / ZIL / L2ARC High-Endurance Write Caching
Dell PowerEdge, HPE ProLiant, and Supermicro SFF Server Caddies
Mission-Critical Server Boot & Transaction Logging Volumes

Key Deployment & Integration Considerations

  • Use in RAID 1/10 for write log volumes to achieve maximum performance and hardware redundancy.
  • Verify that SATA interface runs in AHCI mode for standalone server deployments.
  • SSD is compatible with standard 2.5-inch 7mm drive trays and hot-swap caddies.
