Intel SSD DC S3610 Series 1.6TB SATA Enterprise SSD
Technical Specifications
Hardware Features
Network Performance
System and Support
General Specifications
Product Description
Intel SSD DC S3610 Series 1.6TB SATA Enterprise SSD
Need extreme write endurance and rock-solid reliability for demanding server databases or caching tiers? The Intel SSD DC S3610 Series 1.6TB SATA Enterprise SSD is a high-endurance, mixed-use enterprise SATA solid-state drive built with genuine Intel 20nm High Endurance Technology (HET) MLC NAND. Engineered for write-heavy database transaction logging, hypervisor swap partitions, dynamic caching layers, and high-frequency OLTP workloads, it delivers sequential reads up to 550 MB/s, sequential writes up to 500 mb/s, and Up to 84,000 IOPS (4KB) random-read IOPS. With an extraordinary endurance profile of 10.7 PBW (10,700 TBW) / 3.0 DWPD over 5 years, full capacitor-backed Power Loss Protection, and AES 256-bit encryption, the DC S3610 ensures sustained multi-year endurance and data protection for mission-critical enterprise server environments in Bangladesh.
Enterprise Performance and Architectural Overview
Unlike standard read-centric TLC SSDs, the Intel SSD DC S3610 Series utilizes premium High Endurance Technology (HET) Multi-Level Cell (MLC) flash silicon. This specialized memory architecture allows the drive to handle 3 full drive writes per day (3.0 DWPD) continuously for 5 years without performance degradation. With dedicated hardware power-loss protection capacitors, end-to-end data integrity protection, and 2.0 million hours MTBF, the DC S3610 is ideal for database write logs (WAL), hyper-converged storage nodes, caching tiers, and enterprise server boot drives across Bangladesh.
Advanced Technical Standards and Multi-Gigabit Support
- Intel 20nm HET MLC NAND: Industrial-grade High Endurance Technology MLC flash delivers exceptional write endurance (3.0 DWPD) and long-term data retention.
- Massive Write Endurance (10.7 PBW (10,700 TBW) / 3.0 DWPD): Designed for write-intensive enterprise workloads, providing 10.7 PBW (10,700 TBW) / 3.0 DWPD over 5 years of continuous non-stop writing.
- Enhanced Power Loss Protection (PLP): Full discrete tantalum capacitor array guarantees that all in-flight cache writes are flushed safely to flash if server power fails.
- Predictable Consistent I/O Performance: Delivers up to 550 MB/s sequential read, Up to 500 MB/s write, and stable low-latency IOPS under full queue depths.
- End-to-End Data Path Protection: Internal controller circuitry performs multi-stage parity and CRC checks to prevent any silent data corruption.
- Hardware AES 256-bit Encryption: Provides real-time hardware-level data encryption to protect enterprise database records and confidential assets.
Reliability and Long-Term Performance in Bangladesh
Electronic components and network equipment in our region need to be durable to handle varying environmental conditions. Every enterprise unit supplied by INOVEXA Technologies is tested under intensive operational benchmarks to guarantee 24/7 continuous operation, optimized thermal airflow, and long lifespan.
Secure Your High-Performance Hardware at INOVEXA
Do not let hardware bottlenecks hold back your business network or workstation. We maintain ready stock of genuine enterprise hardware backed by fast nationwide delivery across Bangladesh, replacement warranty, and dedicated engineering support.
Benefits & Enterprise Applications
Enterprise Applications & Deployments
Database Write-Ahead Logging (WAL / Redo Logs)
Handles high-frequency write commits in Oracle, PostgreSQL, MySQL, and MS SQL databases without wearout.
Hypervisor Swap & Dynamic Caching Layers
Acts as a high-speed L2 caching layer in ZFS (L2ARC/SLOG), Ceph, and VMware vSAN pools.
High-Density Virtualization Clusters
Provides resilient shared storage for mixed-workload virtual machines with heavy write cycles.
Enterprise OS Boot & Log Partitions
Ensures zero downtime and data protection for mission-critical Linux/Windows server operating systems.
Financial & Transaction Processing Nodes
Maintains sub-millisecond commit latency and hardware encryption for transactional systems.
Operational & ROI Benefits
Extreme 3.0 DWPD Endurance
Outlasts standard TLC SSDs by 3x to 5x in heavy write-intensive enterprise applications.
Genuine Intel HET MLC NAND
Utilizes high-endurance 2-bit-per-cell MLC flash for greater stability under continuous write stress.
Full Hardware Power-Loss Protection
Prevents in-flight data corruption and file system inconsistencies during power outages.
Universal SATA Compatibility
Drop-in replacement for any 2.5-inch SATA drive tray in Dell, HPE, Supermicro, or Cisco servers.
System & Hardware Compatibility
Certified Operating Systems & Hypervisors
- VMware ESXi 6.7/7.0/8.0
- Proxmox VE 7/8
- Windows Server 2016/2019/2022
- RHEL 7/8/9
- Ubuntu Server 20.04/22.04/24.04
- Debian
- FreeBSD / TrueNAS
Hardware Chassis & Interconnect Platform
- Dell PowerEdge (13G/14G/15G)
- HPE ProLiant (Gen9/Gen10/Gen11)
- Supermicro X10/X11/X12
- Cisco UCS
- Lenovo ThinkSystem
- Standard SATA Server Motherboards
Supported Network & Storage Protocols
Deployment & Buying Guide
Recommended Deployment Pairing
Designed for any enterprise server or workstation with 2.5-inch SATA drive bays and SATA 6Gb/s backplanes.
Ideal Infrastructure Use Cases (Best For)
Key Deployment & Integration Considerations
- Use in RAID 1/10 for write log volumes to achieve maximum performance and hardware redundancy.
- Verify that SATA interface runs in AHCI mode for standalone server deployments.
- SSD is compatible with standard 2.5-inch 7mm drive trays and hot-swap caddies.
